TP-Link VIGI NVR1008H-8MP
VIGI 8 Channel PoE+ Network Video Recorder
The TP-Link VIGI NVR1008H-8MP is an 8-channel network video recorder with a built-in PoE switch: eight cameras connect over a single network cable each, with no separate power adapters. That makes installation in an office, shop, warehouse or small production site much simpler and cuts down on cabling.
The unit has 8× 10/100 Mbps PoE+ ports with a total PoE budget of 113 W. It outputs 4K (3840 × 2160) over HDMI, and HDMI and VGA work at the same time. Decoding capacity covers eight channels at 2 MP or four channels at 4 MP, and eight channels can be played back together. Incoming bandwidth is 80 Mbps and outgoing 60 Mbps.
A single SATA bay takes a hard drive of up to 10 TB, and H.265+ compression keeps a longer archive on the same drive. The unit is managed remotely through the VIGI mobile app and VIGI Security Manager.
- 8-channel NVR with built-in PoE switch
- 8× 10/100 Mbps PoE+ ports
- PoE budget: 113 W
- 4K (3840 × 2160) HDMI output
- Simultaneous HDMI and VGA output
- Decoding: 8 channels @ 2 MP / 4 channels @ 4 MP
- 1× SATA — up to 10 TB
- H.265+ compression
The recorder works with VIGI cameras and the VIGI Security Manager software. Sold in Baku with official partner warranty.
| Video and Audio | |
|---|---|
| IP Video Input | 8-Channel |
| Incoming Bandwidth | 80 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840×2160/30Hz, 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| Video Output Mode | HDMI/VGA Simultaneous Output |
| Multi-View Display | 1/4/6/8 |
| DECODING | |
|---|---|
| Audio Compression | G.711A/G.711U/G.726 |
| Video Compression | H.265+/H.265/ H.264+/H.264 |
| Record Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 8-Channel |
| Capability | 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP |
| Record Management | |
|---|---|
| Record Mode | • Manual Recording • Scheduling Recording • Motion Detection Recording |
| Playback Mode | • Instant Playback • Regular Playback • Tag Playback • Event Playback |
| Backup Mode | • Regular Backup • Video Clip Backup |
| Playback Function | • Play • Pause • Stop • Fast Forward • Fast Backward • Play By Frame • Full Screen • Video Clip • Export Clip • Digital Zoom • Lock Recording • Audio On/Off |
| NETWORK | |
|---|---|
| Protocol | UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
| Mobile Phone Access | Android, iOS |
| Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability | ONVIF, CGI |
| External Interface | |
|---|---|
| Network Interface | 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 2× USB 2.0 |
| Audio Interface | 1-ch RCA Input; 1-ch RCA Output |
| Alarm In/Out | N/A |
| Serial Interface | N/A |
| Power | 1× DC Jack |
| Reset Button | 1 |
| Speaker | N/A |
| eSATA | N/A |
| HDMI | 1 |
| VGA | 1 |
| HARD DISK | |
|---|---|
| SATA | 1 SATA Interface |
| Capacity | Up to 10 TB Capacity for Each HDD |
| PoE | |
|---|---|
| Standard | 802.3at/af Compliant |
| Interface | 1- 8, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| PoE Budget | 113 W Available for All PoE+ Ports, 30 W Max per Port |
| Alarm | |
|---|---|
| General Alarm | • Motion Detection • Video Tampering • Scene Change Detection • Line-Crossing Detection • Intrusion Detection • Region Entering Detection • Region Exiting Detection • Loitering Detection • Object Abandoned/Removal Detection • Vehicle Detection • Human Detection • Abnormal Sound Detection • Smart Frame |
| Anomaly Alarm | • Video Loss • Offline and IP Conflict • Disk Exception • Login Exception |
| Alarm Linkage | • Recording • White Light Alarm • Buzzer • Log • Audible Alarm |
| GENERAL | |
|---|---|
| Storage Temperature | -40–70 °C |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Package Contents | • VIGI Network Video Recorder • Power Adapter • HDD Screws • Mouse • Quick Installation Guide |
| Working Temperature | NVR: -10–55 °C Power Adapter: 0–40 °C |
| Working Humidity | 10%~90% RH Non-Condensing |
| Dimensions( W X D X H ) | 294 × 180 × 44 mm |
| Net Weight | 1.12 Kg |
| Gross Weight | 2.2 Kg |
| Power Supply | 53.5V DC/2.43A |
| Power Consumption | • 2.38 W (Without Disk) • 12.94 W (With Disk) |
| Certifications | CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI |
Related Products
TP-Link VIGI NVR1008H-8MP — surveillance camera for business
TP-Link VIGI NVR1008H-8MP belongs to the TP-Link VIGI line: a surveillance camera for shops, warehouses, offices and production sites. Unlike home cameras it is built around an NVR recorder, power over a single cable via PoE, and continuous long-term recording.
Who it suits: sites with four cameras or more, shop chains that need several locations on one NVR, warehouses and offices recording around the clock. Together with a PoE switch you no longer need a separate power supply at every camera.
Key specifications
| 8-channel NVR with built-in PoE switch | |
| 8× 10/100 Mbps PoE+ ports | |
| PoE budget | 113 W |
|---|---|
| 4K (3840 × 2160) HDMI output | |
| Simultaneous HDMI and VGA output | |
| Decoding | 8 channels @ 2 MP / 4 channels @ 4 MP |
| 1× SATA | up to 10 TB |
| H.265+ compression | |
Price in Baku, delivery and installation
Ask us for the current price and stock — every device is sold with the official TP-Link warranty and delivery in Baku is available.
If you also need installation, our Camera installation service starts from 40 ₼; the site visit and quote in Baku are free and we give a 6-month warranty.
Before you choose
For a comparison with the closest models, a price table and buying advice, see the guide for this category.
A detailed article on this topicWhat Is VIGI Security Manager? Monitor and Set Up VIGI Cameras on a PC Read →
Frequently asked questions about TP-Link VIGI NVR1008H-8MP
Do I have to buy an NVR for TP-Link VIGI NVR1008H-8MP?
Not strictly — the camera can record to a memory card. But from four cameras up, an NVR keeps the archive in one place, makes searching through recordings far easier, and preserves the footage even if a camera is damaged. On a larger site the NVR and the PoE switch are planned together.
What is PoE and why does it matter?
PoE carries both data and power over one network cable. That means no separate socket next to the camera, so the installation is cheaper and tidier. The important part is choosing a PoE switch with enough power budget (W) for the number of cameras.
Do you design the system for a site?
Yes. The number of cameras, viewing angles, cable routes and NVR capacity are decided after a site visit. The visit and the quote are free anywhere in Baku.
What about warranty and delivery?
The device is sold by the official TP-Link partner in Azerbaijan with official warranty. Delivery in Baku is available and shipping to the regions is possible. If you need installation, see our services page.
