TP-Link Flex Bridge 5
TP-Link Flex Bridge 5 – şəkil 2
TP-Link Flex Bridge 5 – şəkil 3
TP-Link Flex Bridge 5 – şəkil 4
TP-Link Flex Bridge 5 – şəkil 5
TP-Link Flex Bridge 5 – şəkil 6

TP-Link Flex Bridge 5

Omada 5 GHz 867 Mbps Long-Range Wireless Flex Bridge

Original price was: 408 ₼.Current price is: 370 ₼.

Birbank logo
Installment payment calculator with Birbank
Installment payment terms apply to the non-discounted price
0%
2 mon.
0%
3 mon.
0%
4 mon.
0%
5 mon.
0%
6 mon.
Monthly payment 204 ₼
  • Works with Flex & Sector Bridges: Point-to-point and point-to-multipoint bridging: optimized for 8 nodes, up to 32 with a Sector Bridge hub.*
  • 5 GHz 867 Mbps up to 3.1 miles: Ideal for extending networks across buildings and remote locations.△
  • 2× PoE Out Ports: 3 Gigabit PoE ports including 2 PoE Out ports, easily powering IP cameras.
  • Role & DIP Switches for Simple Pairing: Seamless role switching with a DIP switch reduces configuration and deployment complexity.
  • Easy Alignment with Ball-Joint: Flexible wall and pole mounting allows quick angle adjustment.
  • Industry-Leading IP66 Weatherproof: IP66 and 6 kV lightning protection safeguard your network outdoors.**
  • Flexible Power Supply: Supports 802.3at/af, Passive PoE (54 V adapter included) and 12 V DC.
  • App-Guided Alignment: Align the bridge with real-time signal strength visualization in the Omada app.
HARDWARE FEATURES
Interface3× Gigabit Ethernet Ports (2 Support PoE Out)
ButtonReset
DIP Switch• Role Switch
• Pairing Code Switch
Power Supply• 12V DC
• 802.3at/af PoE
• 24V Passive PoE (54V Passive PoE Adapter Included – For Dry Indoor Use Only)
Max. Power ConsumptionDC: 12W
PoE: 26.06W with PoE out
Dimensions ( W x D x H )8.4 × 2 × 4.7 in (214.2 × 50.8 × 119.8 mm)
Antenna• 2.4 GHz: 1 × 1 dBi (peak gain), internal omnidirectional antennas
• 5 GHz: 2 × 17 dBi (peak gain), internal directional antennas
• Beamwidth: Horizontal 40°, Vertical 18°
Weatherproof EnclosureIP66
MountingPole and wall mounting (Kits included)
Management Features
Omada AppYes
Restore & BackupYes
Firmware update via WebYes
NTPYes
Centralized Management• Omada Central (Cloud-Based)
• Omada Hardware Controller
• Omada Software Controller
Cloud AccessYes. Require the use of an Omada Controller.
Email AlertsYes
LED ON/OFF ControlYes
SNMPYes
SSHYes
Web-based ManagementYes
Zero-Touch ProvisioningYes
WIRELESS FEATURES
PtPYes
PtMP8 Maximum
Transmission Distance5,000 m (3.1 mi)
Wireless StandardsIEEE 802.11 a/n/ac
Frequency• 2.4 GHz (Device Management Only)
• 5 GHz
Signal Rate5 GHz: Up to 867 Mbps
Wireless Functions• MU-MIMO: 5G 2×2 MU-MIMO DL
• Multiple SSIDs: 1
• Wireless Statistics
• Reboot Schedule
• RADIUS Accounting
• Static IP/Dynamic IP
• Rate Limit
• Enable/Disable Wireless Radio
• Enable/Disable SSID Broadcast
Wireless Security• VLAN
• Rogue AP Detection
• Wireless Encryption
Transmission Power• CE:
<23dBm (5 GHz, band 1/2, EIRP)
<30dBm (5 GHz band3, EIRP)
• FCC:
<23.5dBm (5 GHz band1)
<25dBm (5 GHz band4)
OTHERS
CertificationCE, FCC, RoHS
Package Content• Flex Bridge 5
• Installation Guide
• Mounting Kit
• Passive PoE Adapter
• Power Cord
Lightning Protection• Air discharge: ±8kV
• Contact discharge: ±4kV
• Common mode 10/700: ±6kV
Environment• Operating Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing
Weight0.59 kg (1.3 lbs)

Reviews

There are no reviews yet.

Be the first to review “TP-Link Flex Bridge 5”

Your email address will not be published. Required fields are marked *

Related Products

TP-Link Flex Bridge 5 — Omada access point

TP-Link Flex Bridge 5 is part of the TP-Link Omada system: it is built to give steady Wi-Fi to many users at once — in an office, shop, cafe, hotel or warehouse. Unlike a home router it holds a large number of devices in parallel and is managed centrally.

Who it suits: places where 20–30 or more devices connect, offices spread over several rooms, shops and cafes that need guest Wi-Fi. The access points are gathered into one panel through an Omada controller (OC200 or cloud), and the guest network is kept separate from the main one.

Key specifications

Works with Flex & Sector BridgesPoint-to-point and point-to-multipoint bridging: optimized for 8 nodes, up to 32 with a Sector Bridge hub.*
5 GHz 867 Mbps up to 3.1 milesIdeal for extending networks across buildings and remote locations.△
2× PoE Out Ports3 Gigabit PoE ports including 2 PoE Out ports, easily powering IP cameras.
Role & DIP Switches for Simple PairingSeamless role switching with a DIP switch reduces configuration and deployment complexity.
Easy Alignment with Ball-JointFlexible wall and pole mounting allows quick angle adjustment.
Industry-Leading IP66 WeatherproofIP66 and 6 kV lightning protection safeguard your network outdoors.**
Flexible Power SupplySupports 802.3at/af, Passive PoE (54 V adapter included) and 12 V DC.
App-Guided AlignmentAlign the bridge with real-time signal strength visualization in the Omada app.

Price in Baku, delivery and installation

The current price on the site is 370 ₼. It includes the official TP-Link warranty, delivery in Baku and shipping to the regions on request.

If you also need installation, our Office network setup service starts from 200 ₼; the site visit and quote in Baku are free and we give a 6-month warranty.

Before you choose

For a comparison with the closest models, a price table and buying advice, see the guide for this category.

A detailed article on this topicWhat Is Omada? Business Wi-Fi for Offices, Cafés and Hotels Read →

Frequently asked questions about TP-Link Flex Bridge 5

Do I need a controller for TP-Link Flex Bridge 5?

A single access point can run in standalone mode. From two points up a controller (the OC200 hardware, or the software/cloud version) makes life much easier: every point appears in one panel, settings are entered once, and roaming between points behaves properly.

How is it powered?

The access points are powered over the network cable via PoE — no socket needed in the ceiling. A PoE switch or the injector in the box does the job; as the number of points grows a PoE switch becomes the cheaper option.

Can I set up guest Wi-Fi in a cafe?

Yes. In Omada the guest network is a separate SSID with access to the main network blocked, and you can add a login portal, time limits and speed limits.

What about warranty and delivery?

The device is sold by the official TP-Link partner in Azerbaijan with official warranty. Delivery in Baku is available and shipping to the regions is possible. If you need installation, see our services page.
